The IDEX Inline Solvent Filter, Male End, 2 µm, 1/16 in OD (A-314-02; Cole-Parmer item 02010-05) is a high-pressure filtration component for chromatography solvent flow paths. Its stainless steel housing and replaceable 2 µm frit help prevent particulate contamination from reaching sensitive system components.
Key Features
- Fine 2 µm solvent filtration, helping retain particulate matter before it reaches downstream chromatography components
- High-pressure operation up to 6000 psi, supporting compatible HPLC solvent flow paths
- Male-end connection configuration, providing the specified orientation for suitable inline filter assemblies
- Compatible with 1/16 in OD tubing, allowing connection with commonly used high-pressure chromatography fittings
- Durable stainless steel housing, providing a robust body for compatible solvent filtration applications
- Stainless steel frit with PEEK sealing ring, combining a metal filtration surface with a polymer seal
- Replaceable frit design, allowing the filtration element to be renewed without replacing all associated system components
- Supplied with one A-100 frit, providing a 2 µm stainless steel replacement frit with PEEK ring
Note: For effective system protection, the filter should be installed in the flow path between the pump and the injection valve or autosampler using compatible fittings.
Benefits
- Helps protect injection valves, columns and other sensitive components from particulate contamination.
- Reduces the likelihood of flow restrictions caused by particles released from solvents or pump seals.
- Supports routine preventive maintenance through a readily replaceable filtration element.
- Integrates into compatible high-pressure chromatography systems using standard 1/16 in OD tubing.
Why Choose the IDEX Inline Solvent Filter, Male End, 2 µm (A-314-02)?
The IDEX A-314-02 combines 2 µm filtration, stainless steel and PEEK construction, and a 6000 psi pressure rating in a compact male-end configuration. John Morris Group can assist with confirming system compatibility and selecting replacement frits, tubing and high-pressure chromatography fittings.
