The Cole-Parmer High-Accuracy Compound Transmitter, -14.7 To 15 psi, 4 To 20 mA (68073-00) is a stainless steel compound pressure transmitter designed for demanding pressure and vacuum measurement applications. It provides a -14.7 to 15 psi pressure range, ±0.13% full-scale accuracy, 4 to 20 mA output and NEMA 4/IP65-rated housing.
Key Features:
- Brand: Cole-Parmer
- Product Type: High-accuracy compound pressure transmitter
- Part Number: 68073-00
- Cole-Parmer Item Number: 6807300
- Pressure Range: -14.7 to 15 psi
- Accuracy: ±0.13% full-scale
- Output: 4 to 20 mA
- Power: 12 to 28 VDC, unregulated
- Process Connection: 1/4 inch NPT(M)
- Electrical Connection: 2 ft (0.6 m) cable
- Wetted Materials: 17-4PH stainless steel
- Housing: Stainless steel
- Enclosure Rating: NEMA 4, IP65
- Temperature Range: -40 °C to 126 °C (-40 °F to 260 °F)
- Media Compatibility: Gases and liquids compatible with wetted materials
- Dimensions: 5 inch length x 2 inch diameter (12.7 cm x 5.1 cm)
Benefits:
- Supports pressure and vacuum measurement across a compound -14.7 to 15 psi range.
- 4 to 20 mA output supports integration with compatible monitoring and control systems.
- Stainless steel housing and NEMA 4/IP65 rating support demanding industrial environments.
- EMI/RFI resistance helps support accurate and consistent performance in electrically noisy applications.
- Adjustable zero and span potentiometers help improve setup accuracy.
- 17-4PH stainless steel wetted material supports use with compatible gases and liquids.
Why Choose The Cole-Parmer High-Accuracy Compound Transmitter, -14.7 To 15 psi, 4 To 20 mA (68073-00)?
The Cole-Parmer High-Accuracy Compound Transmitter, -14.7 To 15 psi, 4 To 20 mA (68073-00) is suited to applications requiring accurate compound pressure measurement with a robust stainless steel housing and industrial output signal. John Morris Group supplies Cole-Parmer pressure transmitters and measurement instruments for laboratory, industrial and process monitoring applications across Australia.
