Test Methods: ASTM D2887, ASTM D3710, ASTM D5307, ASTM D6352, ASTM D7096, ASTM D7169, ASTM D7213, ASTM D7398, ASTM D7500, EN 15199, EN ISO 3924, IP 406, IP 480, IP 507, ISO 3924
Description
AC Analytical Controls®, the global SIMDIS market leader, provides a full range of solutions that accurately determine true boiling point data from naphtha up to crude oil samples.
Applications
Simulated Distillation, Atmospheric Distillation, Gasoline, Crude, Petrochemical Analysis
Features & Benefits
Full range of SIMDIS applications determines boiling points up to C120.
- Product range includes several unique solutions:
- PAC proprietary Temperature Programmable Inlet. The only SIMDIS dedicated inlet for best performance
- AC 8634 analyzer for accelerated D 86 data of jet fuel and diesel
- Crude Oil analyzer merges DHA Front End with High Temp SIMDIS Technique
- Sulfur and Nitrogen SIMDIS solutions to determine sulfur and nitrogen distributions in Crude or finished products
- Wax ASTM D 5442 application
- Solutions comply with ASTM, CEN, DIN, IP and ISO SIMDIS methods
- A broad set of calibration, reference and quality control samples completes each SIMDIS application
- User group meetings and Performance Monitoring program help users network to maintain analyzer performance
- SIMDIS software is compatible with major chromatographic data systems
- Dedicated correlations and calculations are included for:
- Correlation to Physical Distillation D 86 D 1160 (ASTM D 2887; IP 406; ISO 3924)- NOACK - DIN 51.581-2- MOV - ASTM D 6417- Conversion to volume % for crude oils- Cutpoints fractions- Flashpoint (ASTM D 7215)
- Excellent LIMS connectivity: upload the results directly to your LIMS or manually after approval
- Use of pre-programmed “Products” (sample types), Automatic sample type recognition, blank subtraction, calibration and system validations. Customer selective start and end algorithm, Carbon Number overlay, BP x-axis chromatogram, QC check reports, C or F. Customizable QC sample defintions
- Support Spanish, Chinese, Portuguese, Russian, Korean and French languages
- Compatible with major CDS (OpenLab, EZChrom, ChemStation, Chromeleon, ChromPerfect, Galaxie, Atlas, Kompass
