Operating pressure: 21 MPa (3,000 psi)
Pump type: Variable displacement pumps
Filtration: Full flow on the return side
Maximum ambient operating temperature: 40°C (104°F)
Flow rates (for 60 Hz models): 41.6 lpm (11 gpm)
Flow rates (for 50 Hz models): 37.9 lpm (10 gpm)
*Noise level: 60 dB(A)
Reservoir capacity (maximum): 174 L (46 gal)
* Sound levels [dbA] are expressed as a free field value. Readings may vary with acoustic environment.
Unit dimensions
Width: 77.0 cm (30.3 in)
Height: 120.1 cm (47.3 in)
Length: 114.6 cm (45.1 in)
Weight (with maximum oil) :544 kg (1,200 lb)
Motor size: 18.5 kW (25 hp)
Minimum ambient operating temperature: 5°C (40°F)
