The MATEST Compression / Flexural Testing Machine with dual measuring range 500/15 kN and manual operation is designed for versatile testing of cement and mortar specimens, bricks, rocks, and refractories. Built with a robust two‑column high‑stiffness frame and equipped with two precision gauges, this machine ensures accurate, repeatable results across both compression and flexural tests in demanding laboratory settings.
Product Features
- Dual measuring range: 500 kN and 15 kN for comprehensive compression and flexural testing
- Manual operation with two precision gauges for clear and reliable readings
- Two high‑accuracy pressure transducers providing Class 1 accuracy starting from 10% of the scale
- Max. vertical daylight between platens: 185 mm to accommodate various specimen sizes
- Horizontal daylight between columns: 175 mm allowing flexible positioning of samples
- Platens diameter: 153 mm ensuring uniform load distribution
- Ram travel approximately 45 mm for effective compression and flexural testing
- Supplied complete with lower compression platen and coupling piece for easy assembly
- Power supply (motorized models): 230V, 1 phase, 50Hz, 750W
- Machine weight: 310–340 kg providing operational stability during testing
Benefits
- Dual range enables testing of both high‑strength and low‑strength specimens in one machine
- Manual gauges provide direct, reliable measurement without the need for complex electronics
- Robust frame and quality transducers ensure repeatable, accurate results
- Easy setup with included platen and coupling piece minimizes downtime
- Stable design supports consistent and safe operation in lab environments
Why Choose the MATEST Press Dual Range 500/15 kN Autotec?
Ideal for laboratories seeking a versatile and robust solution, the MATEST Press Dual Range 500/15 kN with manual operation combines high‑capacity compression and flexural testing in a single machine. With its precision gauges, solid construction, and dual range capability, it’s perfectly suited for a wide variety of cement, mortar, brick, and refractory testing applications.
