The Leybold TURBOVAC MAG W 1700 iP DN 250 CF PROFIBUS with bottom-mounted controller is a high-performance, magnetically levitated turbomolecular vacuum pump optimized for industrial and research applications requiring superior throughput and precise control. Featuring a PROFIBUS interface and fully integrated electronics, this pump simplifies installation, reduces cabling, and delivers up to 2100 l/s pumping speed for nitrogen. The bottom-position controller design supports vertical system configurations, while the compact CF flange offers compatibility with ultra-high vacuum setups.
Product Features
- MagLev turbomolecular vacuum pump with integrated controller and power supply
- DN 250 CF flange for high vacuum system compatibility
- Pumping speed up to 2100 l/s for N₂
- Bottom-position controller ideal for vertical or compact system layouts
- PROFIBUS interface for advanced system communication and control
- 5-axis active magnetic bearing system for wear-free, vibration-free operation
- Maintenance-free, hydrocarbon-free performance
- IP54-rated housing for use in harsh industrial environments
- Robust against particulates and corrosive gases
- Self-diagnostic and protective features for safe operation
High Vacuum Pumps
Leybold offers a broad range of different high and ultra high vacuum pumps. These pumps vary in the principle of operation and field of application: turbomolecular vacuum pumps of the TURBOVAC and MAG series, diffusion vacuum pumps DIP and cryo vacuum pumps of the COOLVAC series. Important items for the selection of the adequate high vacuum pump are: attainable ultimate pressure, required pumping speed, gas throughput or compression.
TURBOVAC / TURBOVAC MAG – Turbomolecular Pumps
Leybold Vacuum offers different product lines of turbomolecular vacuum pumps which vary in the rotor suspension. One of them is the TURBOVAC line with mechanical rotor suspension, another one is the TURBOVAC MAG line with magnetic rotor suspension and finally the TURBOVAC i Series with hybrid rotor suspension. Each product line contains “classic” turbomolecular pumps as well as turbomolecular pumps with a compound stage, whereby smaller backing pumps can be used.
TURBOVAC MAGiNTEGRA – Magnetic Rotor Suspension / Integrated Frequency Converter
Accuracy, precision and reliability—those are the features of these magnetically levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Benefits
- Efficient pump-down times with high nitrogen throughput
- Space-saving bottom-mounted control for system flexibility
- Seamless automation with PROFIBUS connectivity
- Reliable, maintenance-free operation with no mechanical wear
- Ideal for precision, clean, and high-load vacuum environments
- IP54-rated construction suitable for industrial applications
Why Choose the Leybold TURBOVAC MAG W 1700 iP?
The Leybold TURBOVAC MAG W 1700 iP DN 250 CF PROFIBUS with bottom control position offers next-generation vacuum performance with smart connectivity, compact footprint, and magnetic levitation technology. Perfect for semiconductor, coating, and R&D facilities requiring precision, cleanliness, and maximum uptime.
