The GUNT HM 250.06 - Free Discharge accessory enables investigation of horizontal discharge from a tank, analysing how outlet shape and outlet velocity affect the trajectory of a water jet. This principle is essential in hydraulic engineering applications such as dam design.
Product Features
- Studies horizontal discharge and water jet trajectory from a tank
- Transparent tank with horizontal outlet and various inserts
- Trajectory digitally recorded in transparent experimental section
- Depth slide gauge measures water jet trajectory at 8 predefined positions
- Measured values transferred to HM 250 base module and displayed on touch screen
- Tank level set and automatically controlled via base module
- Four outlet inserts with different diameters and inlet contours included
- Pressure loss coefficient determined for different inserts
- Investigates influence of tank level and pressure loss on water jet trajectory
- Easily positioned on HM 250 base module worktop
- Automatic accessory recognition via RFID and automatic GUNT software loading/configuration
- Intuitive user interface guides through experiments
- Up to 10 external workstations can track and evaluate experiments via LAN
- Base module supplies water and measures flow rate and pressure
Benefits
- Provides clear understanding of free discharge and jet trajectory principles
- Supports study of pressure loss coefficients and outlet design effects
- Safe and easy setup with automatic software configuration
- Multi-user capability for simultaneous experiment tracking and evaluation
Why Choose GUNT HM 250.06 - Free Discharge?
This accessory provides a reliable solution for analysing water jet trajectories and outlet effects, supporting precise experimental results and enhancing understanding of hydraulic principles.
