The Horiba U-52G Multiparameter Water Quality Meter, GPS, 30 m Cable (99600-27) is a handheld water quality checker for simultaneous field measurement of key environmental water parameters with location data. The U-52G 30 m configuration measures pH, ORP, conductivity, TDS, salinity, dissolved oxygen, turbidity, seawater specific gravity, temperature and water depth, with built-in GPS, USB data transfer and memory for up to 10,000 data sets.
Key Features
- Brand: Horiba
- Model / Part Number: U-52G
- Manufacturer Model Code: 3200164500
- JMG Item Number: 99600-27
- Product Type: Multiparameter water quality meter with GPS
- Cable Length: 100 ft (30 m)
- Measured Parameters: pH, ORP, conductivity, TDS, salinity, dissolved oxygen, turbidity, seawater specific gravity, temperature and water depth
- GPS: Built-in GPS for recording location data with measurements
- pH Range: pH 0 to 14
- ORP Range: -2000 to +2000 mV
- Conductivity Range: 0 to 10 S/m (0 to 100 mS/cm)
- TDS Range: 0 to 100 g/L
- Salinity Range: 0 to 70 PPT
- Dissolved Oxygen Range: 0 to 50.0 mg/L
- Turbidity Range: 0 to 800 NTU
- Turbidity Method: LED light source and 30° scattering method
- Water Depth Range: 0 to 30 m
- Water Depth Method: Pressure method
- Seawater Specific Gravity Range: 0 σt to 50 σt
- Temperature Range: -10 to 55 °C
- Memory: 10,000 data sets
- Communication Interface: USB peripheral
- Control Unit Waterproofing: JIS protection level 7 / IP67 when sensor cable is fitted
- Sensor Probe Waterproofing: JIS protection level 8 / IP68
- Power: Four C-size dry cells
- Included Items: Probe, 500 mL pH 4.0 buffer solution, 250 mL KCl solution, DO sensor installation set, cleaning brush, calibration cup, batteries, shoulder strap and carrying case
Note: The U-52G 30 m model includes GPS, turbidity and water depth measurement. Additional sensors, software and replacement accessories are sold separately where applicable.
Benefits
- Measures multiple water quality parameters and GPS location data with one handheld field instrument.
- Supports environmental surveys where water quality results need to be linked with sampling locations.
- Adds turbidity, water depth and 30 m cable deployment capability for broader field monitoring workflows.
- Supports surface water, groundwater, wastewater and field sampling applications where longer probe reach is required.
- Stores up to 10,000 data sets for field monitoring and later transfer to a PC.
- USB connectivity supports convenient data export for reporting and record keeping.
- Rugged waterproof construction supports use in demanding outdoor sampling environments.
- Included probe, calibration accessories, batteries, strap and case support practical field deployment.
Why Choose the Horiba U-52G Multiparameter Water Quality Meter, GPS, 30 m Cable (99600-27)?
The Horiba U-52G Multiparameter Water Quality Meter provides a field-ready solution for monitoring pH, ORP, conductivity, dissolved oxygen, turbidity, depth, GPS location and related water quality parameters. John Morris Group supplies this Horiba meter to support reliable environmental surveys, wastewater testing and on-site water quality analysis workflows.
